Grille LED Display

Transparent grille-style screens with high ventilation rate and low wind load, ideal for building facades where airflow and weight are critical factors.

Choose Your Grille LED Display

Facade, window or highway — see-through grille screens for every outdoor surface.

Facade grid LED display

Lightweight grille screens that turn building walls into media space.

Window grille LED screen

Window-mounted screens that attract passers-by without blocking daylight.

Highway grille billboard

Wind-permeable large-format billboards with remote cluster control.

Key Features

High Transparency

Up to 70% see-through rate preserves natural lighting and airflow.

Low Wind Load

Reduced structural pressure on building facades.

Lightweight Design

Simplified steel structure reduces installation cost.

Invisible Structure

Minimal visual obstruction from a distance.

Technical Specifications

ParameterSpecification
Pixel PitchP10 / P16 / P20 / P25 / P31.25
Transparency Rate50% – 70%
Brightness5,500 – 7,000 nits
Cabinet Size500×1000mm / 1000×1000mm
IP RatingIP65
Weight12 – 18 kg / m²
Refresh Rate≥1,920 Hz
MaintenanceFront service

Ideal Applications

Glass Curtain Walls · Building Facades · Stage Backdrops · Shopping Centers
