Lightweight die-cast aluminum cabinets with fast-lock design, engineered for touring, events and temporary installations. Flight-case friendly and quick to assemble.
Indoor or outdoor — pick the setup that matches your venue, then compare specifications.
Die-cast cabinets with silent operation and high refresh rate — for conferences, weddings, exhibitions and studio stages.
Weatherproof 5,000+ nits cabinets with fast lock system and flight-case packing — for festivals, concerts and sports events.
Die-cast aluminum structure reduces transport cost and setup time.
Tool-free connection between cabinets for rapid assembly.
Modular packaging designed for repeated touring use.
Supports ±5° or ±10° curve for creative stage designs.
| Parameter | Specification |
|---|---|
| Pixel Pitch | P2.6 / P2.9 / P3.9 / P4.8 |
| Cabinet Size | 500×500mm / 500×1000mm |
| Brightness | 1,200 – 1,500 nits (indoor) |
| Refresh Rate | ≥3,840 Hz |
| Scan Mode | 1/16, 1/21 |
| IP Rating | IP40 (indoor) |
| Weight | 7.5 kg / cabinet (500×500mm) |
| Curve Angle | ±5° / ±10° |
Concerts · Exhibitions · Corporate Events · Stage Production
